ASPEE‑HTP PS50 (50 LPM).

🔧 Technical Specifications

According to Aspee’s official documentation:

• Model: HTP PS/50 Horizontal Triplex Power Sprayer

• Pump Type: 3‑piston triplex horizontal pump, stainless steel, oil‑bath lubrication

• Flow Rate: 50 L/min free discharge at 950 RPM

• Normal Working Pressure: ~200 psi (14 bar)

• Maximum Pressure: Up to ~400 psi (28 bar)

• Power Requirement: Approximately 4–5 HP prime mover

• Pump Speed: 950 RPM

• Weight (excl. oil & pulley): ~12 kg

• Dimensions (L × W × H): Approx. 340 × 285 × 300 mm

🧩 Key Features & Benefits

• Compact & Lightweight Construction – At around 12 kg, it’s easy to transport and mount, ideal for handheld or small-engine integration

• Smooth, Oil-Bath Lubricated Triplex Pump – Stainless-steel pistons and oil bath design ensure stable delivery, lower wear, and reduced maintenance.

• Adjustable Pressure Delivery – Operates at ~200 psi for regular use, and up to 400 psi when deeper canopy penetration or higher spray force is needed.

• High Flow Capability – Suitable for simultaneous use of 4–5 spray guns, significantly boosting spraying throughput.

• Complete Accessories Supplied – Typically includes: pulley, pressure vessel, gauge, bypass / regulator valve, ~3 m bypass hose, suction hose with strainer, and delivery couplings

🌾 Applications

• Large-scale orchard spraying, coffee and tea plantations, field crops

• Agricultural chemical application where uniform spray and flow are critical

• Field irrigation tasks in moderate scale setups

• Multi-gun spraying systems – supports parallel operation of 4–5 spray guns for wide coverage

📊 Summary Table

✅ Benefits at a Glance

• High-efficiency performance for spraying throughputs

• Robust and low-maintenance pump design that requires minimal servicing

• Versatile pressure settings to suit different spray applications

• Ergonomic and portable for field portability and flexible setup

• Supports multi-gun operation, enhancing coverage speed
